Technical Parameters
- Rated Temperature：-80℃∽+250℃
- Rated Voltage：600V
- Conductor：solid/stranded Tinned Copper /Silver Copper/Nickel Copper
- Insulation：PFA Teflon
- Color: red, yellow, blue, white, black, green, brown, orange, purple, yellow green, transparent etc.
- Certificate/Standard: GJB773-2000
- Application: widely used in electronic appliances, lighting, instrumentation
|
Section (mm2) |
Conductor No./Dia. (mm) |
Avg. Insulation Thickness (mm) |
Overall Dia. (mm) |
Max. Resistance 20℃（≤Ω/km） |
|
0.035 |
7/0.08 |
0.15 |
0.55 |
525 |
|
0.05 |
7/0.10 |
0.15 |
0.60 |
330 |
|
0.07 |
1/0.30 |
0.20 |
0.70 |
245 |
|
0.08 |
7/0.12 |
0.20 |
0.76 |
227 |
|
0.12 |
7/0.15 |
0.25 |
0.95 |
146 |
|
1/0.40 |
0.20 |
0.80 |
132 |
|
|
0.14 |
7/0.16 |
0.17 |
0.82 |
126 |
|
0.20 |
7/0.20 |
0.30 |
1.20 |
83.5 |
|
0.35 |
19/0.16 |
0.30 |
1.40 |
49.5 |
|
0.50 |
19/0.18 |
0.30 |
1.60 |
36.0 |
|
0.75 |
19/0.23 |
0.30 |
1.75 |
22.7 |
|
1/0.97 |
0.26 |
1.49 |
21.8 |
|
|
1.0 |
19/0.26 |
0.30 |
1.90 |
19.0 |
|
1.2 |
19/0.28 |
0.30 |
2.00 |
15.3 |
|
1.5 |
19/0.32 |
0.35 |
2.30 |
11.7 |
|
2.0 |
19/0.37 |
0.35 |
2.55 |
9.45 |
|
2.5 |
19/0.41 |
0.41 |
2.85 |
6.86 |
|
4 |
37/0.37 |
0.50 |
3.50 |
4.51 |
|
6 |
37/0.45 |
0.50 |
4.20 |
3.05 |
|
8 |
133/0.28 |
0.50 |
5.20 |
2.16 |
|
10 |
133/0.32 |
0.50 |
5.80 |
1.68 |
|
16 |
133/0.39 |
0.60 |
7.20 |
1.13 |
|
20 |
133/0.45 |
0.60 |
8.00 |
0.886 |
|
25 |
196/0.40 |
0.60 |
8.80 |
0.734 |
|
35 |
494/0.30 |
0.70 |
10.40 |
0.511 |
|
50 |
396/0.40 |
0.80 |
12.20 |
0.358 |
|
70 |
551/0.40 |
1.00 |
14.60 |
0.27 |
|
95 |
760/0.40 |
1.20 |
17.20 |
0.21 |
|
Remarks: able to produce according to customer’s requirements |
||||
