Technical Parameters
- Rated Temperature：-80℃∽+250℃
- Rated Voltage：600V
- Conductor：solid/stranded Tinned Copper/Nickel Copper/pure Nickel
- Insulation：PTFE Teflon
- Color: red, yellow, blue, white, black, green, brown, orange, purple, yellow green, off white etc.
- Certificate/Standard: GJB773-2000
- Application: widely used in electronic appliances, lighting, instrumentation
|
Section (mm2) |
Conductor No./Dia. (mm) |
Avg. Insulation Thickness (mm) |
Overall Dia. (mm) |
Max. Resistance 20℃ (≤Ω/km） |
|
0.05 |
1/0.25 |
0.20 |
0.65 |
330 |
|
0.05 |
7/0.10 |
0.20 |
0.70 |
330 |
|
0.07 |
1/0.30 |
0.25 |
0.80 |
245 |
|
0.08 |
7/0.12 |
0.25 |
0.86 |
227 |
|
0.12 |
1/0.40 |
0.25 |
0.90 |
132 |
|
0.12 |
7/0.15 |
0.25 |
0.95 |
146 |
|
0.15 |
7/0.16 |
0.25 |
0.98 |
126 |
|
0.16 |
1/0.45 |
0.25 |
0.95 |
116 |
|
0.20 |
7/0.20 |
0.30 |
1.20 |
83.5 |
|
0.20 |
1/0.50 |
0.30 |
1.10 |
83.5 |
|
0.35 |
19/0.16 |
0.30 |
1.40 |
49.5 |
|
0.50 |
19/0.18 |
0.30 |
1.50 |
36 |
|
0.75 |
19/0.23 |
0.35 |
1.85 |
23.2 |
|
1 |
19/0.26 |
0.35 |
2.00 |
19 |
|
1.2 |
19/0.28 |
0.35 |
2.10 |
15.3 |
|
1.5 |
19/0.32 |
0.40 |
2.40 |
11.7 |
|
2 |
19/0.37 |
0.40 |
2.65 |
9.45 |
|
2.5 |
19/0.41 |
0.40 |
2.85 |
6.86 |
|
4 |
37/0.37 |
0.45 |
3.49 |
4.51 |
|
6 |
37/0.45 |
0.50 |
4.15 |
3.05 |
|
Remarks: able to produce according to customer’s requirement |
||||
