Technical data:
- Rated Temperature:-65℃∽+250℃
- Rated Voltage：Voltage test 2000v,Spark test voltage 4000 v
- Conductor: 316 Steel
- Insulation：Teflon
- Shield:Tinned Copper/Silver Copper
- Jacket:Teflon
- Color:transparent,light brown,blue,etc.
- Conform to ROHS and flame retardant Standard
- Application:Widely used for high frequency signal transmission in communication equipment or other electronic equipment
|
Cable Article NO. |
Conductor No. (mm） |
Conductor Dia. （mm) |
Shield Layers |
Avg.Jacket Thickness（mm） |
OD (mm) |
|
F4PF46-316L |
7/0.10 |
0.87 |
1 |
0.20 |
1.80 |
|
7/0.18 |
1.50 |
1 |
0.25 |
2.55 |
|
|
7/0.18 |
1.50 |
2 |
3.20 |
||
|
1/0.73 |
2.20 |
1 |
3.30 |
||
|
1/0.73 |
2.20 |
2 |
4.00 |
||
|
1/0.93 |
3.00 |
1 |
0.35 |
4.50 |
|
|
1/0.93 |
3.00 |
2 |
5.50 |
||
|
1/1.48 |
4.60 |
1 |
6.40 |
||
|
7/0.82 |
7.30 |
1 |
9.20 |
||
|
Remarks: able to produce voltage class according to customer’s requirement |
|||||
