Technical Parameters
- Rated Temperature：-65℃∽200℃
- Rated Voltage：600V、1140V
- Insulation：Fluoroplastics, special materials made of impregnable paint
- Colors: red, yellow, blue, white, black, green, brown, orange, purple, yellow green, transparent etc.
- Features: With high temperature resistance, low temperature resistance, bending resistance, acid and alkali resistance, oil resistance and flame retardant properties
- Application: widely used in internal wiring of servo motor, rare earth motor, electronic appliance, lamps lighting, etc.
|
Section (mm2) |
Conductor No./Dia. (mm) |
Insulation Thickness (≥mm) |
Overall Dia. (≥mm) |
Max. Resistance 20℃（≤Ω/km） |
|
0.014 |
7/0.05 |
0.15 |
0.45 |
1454 |
|
0.030 |
16/0.05 |
0.15 |
0.50 |
590 |
|
0.035 |
19/0.05 |
0.15 |
0.55 |
568 |
|
7/0.08 |
0.15 |
0.55 |
568 |
|
|
0.05 |
26/0.05 |
0.15 |
0.60 |
356 |
|
10/0.08 |
0.15 |
0.60 |
356 |
|
|
0.07 |
37/0.05 |
0.20 |
0.70 |
260 |
|
19/0.07 |
0.20 |
0.70 |
260 |
|
|
14/0.08 |
0.20 |
0.70 |
260 |
|
|
0.08 |
42/0.05 |
0.20 |
0.78 |
245 |
|
21/0.07 |
0.20 |
0.78 |
245 |
|
|
16/0.08 |
0.20 |
0.78 |
245 |
|
|
0.12 |
63/0.05 |
0.25 |
0.95 |
160 |
|
32/0.07 |
0.25 |
0.95 |
160 |
|
|
24/0.08 |
0.25 |
0.95 |
160 |
|
|
0.20 |
105/0.05 |
0.25 |
1.10 |
90.4 |
|
56/0.07 |
0.25 |
1.10 |
90.4 |
|
|
42/0.08 |
0.25 |
1.10 |
90.4 |
|
|
0.35 |
182/0.05 |
0.25 |
1.30 |
53.1 |
|
96/0.07 |
0.25 |
1.30 |
53.1 |
|
|
70/0.08 |
0.25 |
1.30 |
53.1 |
|
|
0.50 |
259/0.05 |
0.25 |
1.40 |
36.7 |
|
133/0.07 |
0.25 |
1.40 |
36.7 |
|
|
105/0.08 |
0.25 |
1.40 |
36.7 |
|
|
Remarks: able to produce according to customer’s requirements. |
||||
