Technical data:
- Rating Temperature：-80℃∽+200℃、-80℃∽+250℃
- Rating Voltage：30V
- Conductor：Tinned copper wire, silver-plated copper wire
- Insulation：FEP、PFA、PEEK
- Shielding：Tinned Copper, Silver Copper
- Color ：Red, Yellow, Blue, White, Black, Green, Brown, Orange, Purple,Pink,Transparent etc.
- Sheath：FEP、PFA、PEEK
- Application：Suitable for all electrical appliances, lighting fixtures, electronic equipment, temperature sensing and other leadss
|
Gauges AWG |
Construction （No./mm） |
Wire Diameter (mm) |
Overall Diameter (mm) |
Resistance DC at 20℃ （≤Ω/km） |
|
44 |
7/0.02 |
0.15 |
0.27 |
9180 |
|
1/0.05 |
0.15 |
0.27 |
9180 |
|
|
42 |
7/0.025 |
0.17 |
0.29 |
6300 |
|
1/0.07 |
0.17 |
0.29 |
6300 |
|
|
40 |
7/0.03 |
0.19 |
0.31 |
4080 |
|
1/0.08 |
0.19 |
0.31 |
4080 |
|
|
38 |
7/0.04 |
0.22 |
0.34 |
2400 |
|
1/0.10 |
0.22 |
0.34 |
2400 |
|
|
36 |
7/0.05 |
0.25 |
0.37 |
1530 |
|
1/0.12 |
0.25 |
0.37 |
1530 |
|
|
Remarks: able to produce as customer’s requirement |
||||
