Technical Parameters
- Rated Temperature：500℃
- Rated Voltage：300/500V
- Conductor：Nickel
- Insulation：mica glass fiber
- Color: red, yellow, blue, white, mixed colors, etc
- Application: widely used in thermalelectrity, petrol, electromechanical equipment, power plant, drying room, heating light sources, thermalelectrity equipment etc. high temperature working environments
|
Section (mm2) |
Conductor No./ Dia. (mm) |
OD(mm) |
||||||
|
Single core |
Double core |
Triple core |
4 core |
|||||
|
0.5 |
7/0.30 |
3.5 |
4.7*7.6 |
8.0 |
9.0 |
|||
|
0.75 |
11/0.30 |
3.7 |
4.8*7.9 |
8.4 |
9.3 |
|||
|
1.0 |
14/0.30 |
3.8 |
5.0*8.2 |
8.7 |
9.5 |
|||
|
1.5 |
21/0.30 |
4.0 |
5.2*8.5 |
9.1 |
10.2 |
|||
|
2 |
28/0.30 |
4.2 |
5.4*9.0 |
9.5 |
10.8 |
|||
|
2.5 |
35/0.30 |
4.4 |
5.6*9.4 |
10.0 |
11.2 |
|||
|
3.5 |
49/0.30 |
5.0 |
5.8*9.5 |
10.5 |
11.6 |
|||
|
4 |
56/0.30 |
5.3 |
6.3*10.8 |
11.5 |
13.0 |
|||
|
6 |
84/0.30 |
6.0 |
6.8*11.8 |
13.1 |
14.8 |
|||
|
Remarks: able to produce according to customer’s requirement |
||||||||
