Technical Parameters
- Rating Temp：105℃、125℃、150℃
- Conductor：Tinned Copper
- Insulation：XLPE
- Color：red, yellow, blue, white, black, green etc.
- Sheath：LSZH Compound
- Application：internal wiring for Auto
|
Section Area (mm2) |
Construction （No./mm） |
Wire Dia. (mm) |
cores |
Sheath Thickness (mm) |
Resistance at 20℃（≤Ω/km） |
|
0.5 |
16/0.2 |
2.25±0.1 |
≥2core |
≥1.0 |
40.1 |
|
0.75 |
24/0.2 |
2.50±0.1 |
26.7 |
||
|
1 |
32/0.2 |
2.60±0.1 |
20 |
||
|
1.5 |
30/0.25 |
3.15±0.1 |
≥1.5 |
13.7 |
|
|
2.5 |
49/0.25 |
3.65±0.1 |
8.21 |
||
|
4 |
56/0.3 |
4.3±0.1 |
5.09 |
||
|
6 |
84/0.3 |
5.6±0.1 |
≥1.8 |
3.39 |
|
|
10 |
84/0.4 |
6.8±0.2 |
1.95 |
||
|
16 |
126/0.4 |
8.5±0.2 |
≥2.0 |
1.24 |
|
|
25 |
196/0.4 |
9.5±0.2 |
0.795 |
||
|
35 |
276/0.4 |
11.1±0.2 |
0.565 |
||
|
50 |
396/0.4 |
13.2±0.3 |
≥2.5 |
0.393 |
|
|
70 |
360/0.5 |
15.0±0.5 |
0.277 |
||
|
Remarks: able to produce as customer’s requirement |
|||||
