Technical data:
- Rated Temperature:-15℃∽+105℃
- Rated Voltage：300V/500V
- Conductor: High Purity Copper
- Insulation：Special Wear Resistance
- Inner Protective Material:Special Wear Resistance
- Shield:High Purity Copper
- Jacket:Special Wear Resistance
- Feature:Using steel filler to enhance stretch resistance performance
- Application:Electronic industry, machinery, lifting equipment and ship manufacturing, mine, building and transportation, new energy resource etc.
|
Section (mm2) |
Conductor No./mm |
Avg.Insulation Thickness （mm） |
Core No. |
Jacket Thickness（mm） |
Max. Resistance 20℃ （≤Ω/km） |
|
0.50 |
16/0.20 |
≥0.4 |
≥2Core |
≥0.6 |
39.0 |
|
0.75 |
42/0.15 |
26.0 |
|||
|
1.0 |
32/0.20 |
19.50 |
|||
|
1.5 |
30/0.25 |
13.30 |
|||
|
2.5 |
49/0.25 |
7.98 |
|||
|
4 |
56/0.30 |
4.95 |
|||
|
6 |
84/0.30 |
3.30 |
|||
|
Remarks: able to produce according to customer’s requirement |
|||||
