Technical Parameters
- Rated Temperature：-60℃∽＋250℃
- Rated Voltage Class:5KVDC、10KVDC、20KVDC、30KVDC、40KVDC、50KVDC
- Conductor：Silver Copper
- Insulation：PFA or PTFE
- Wire color:Red, yellow, blue,white,green,black,brown,orange,gray.etc.
- Application: high voltage wire for gas ignition device and other electrical apparatus(gas oven, microwave oven automobiles)
|
AWG |
Conductor(mm） |
Overall Dia.(mm) |
Max. Resistance 20℃（≤Ω/km） |
|||||
|
5KVDC |
10KVDC |
20KVDC |
30KVDC |
40K-DC |
50KVDC |
|||
|
24 |
1/0.50 |
1.50 |
1.70 |
1.80 |
2.10 |
2.60 |
2.80 |
89.2 |
|
7/0.20 |
1.60 |
1.80 |
1.90 |
2.20 |
2.70 |
2.90 |
||
|
22 |
7/0.25 |
1.75 |
1.90 |
2.05 |
2.35 |
2.85 |
3.05 |
56.4 |
|
19/0.15 |
1.75 |
1.90 |
2.05 |
2.35 |
2.85 |
3.05 |
||
|
20 |
7/0.32 |
2.00 |
2.10 |
2.30 |
2.60 |
3.10 |
3.30 |
35.3 |
|
19/0.18 |
1.90 |
2.00 |
2.20 |
2.50 |
3.00 |
3.20 |
||
|
18 |
7/0.40 |
2.20 |
2.35 |
2.50 |
2.80 |
3.30 |
3.50 |
22.2 |
|
19/0.23 |
2.15 |
2.30 |
2.45 |
2.75 |
3.25 |
3.45 |
||
|
17 |
19/0.26 |
2.30 |
2.50 |
2.60 |
2.90 |
3.40 |
3.60 |
17.6 |
|
16 |
19/0.30 |
2.50 |
2.70 |
2.80 |
3.10 |
3.60 |
3.80 |
14.0 |
|
14 |
19/0.37 |
2.85 |
3.00 |
3.15 |
3.45 |
3.95 |
4.15 |
8.78 |
|
12 |
19/0.48 |
3.40 |
3.60 |
3.70 |
4.00 |
4.50 |
4.70 |
5.53 |
|
10 |
37/0.43 |
4.05 |
4.20 |
4.35 |
4.65 |
5.15 |
5.35 |
3.47 |
