Technical Parameters
- Rated Temperature：-60℃∽+150℃
- Rated Voltage：600V
- Conductor：18AWG-12AWG solid/stranded Tinned Copper/Nickel Copper
- Insulation：Silicone Rubber
- Color: red, yellow, blue, white, black, green, brown, orange, purple, yellow green, off white etc.
- Certificate/Standard: tested and approved by UL, UL file No.:E311865
- Application: widely used in electronic appliances, lighting, instrumentation
|
AWG |
Section (mm2) |
Conductor No./ Dia. (mm) |
Avg. Insulation Thickness (mm) |
Min. Insulation Thickness (mm) |
Overall Dia. （mm） |
Max. Resistance 20℃（≤Ω/km） |
|
|
18 |
0.80 |
7/0.40 |
0.76 |
0.69 |
2.72 |
23.2 |
|
|
1/1.05 |
0.76 |
0.69 |
2.57 |
24.7 |
|||
|
17 |
1.0 |
32/0.20 |
0.76 |
0.69 |
2.82 |
20 |
|
|
1/1.13 |
0.76 |
0.69 |
2.65 |
19.8 |
|||
|
16 |
1.3 |
7/0.50 |
0.76 |
0.69 |
3.02 |
14.6 |
|
|
1/1.30 |
0.76 |
0.69 |
2.82 |
15.3 |
|||
|
14 |
2.0 |
41/0.25 |
0.76 |
0.69 |
3.37 |
10 |
|
|
13 |
2.5 |
49/0.25 |
0.76 |
0.69 |
3.57 |
8.2 |
|
|
12 |
3.3 |
49/0.30 |
0.76 |
0.69 |
4.22 |
5.64 |
|
|
Remarks: more AWG available, pls. contact us |
|||||||
