Technical data:
- Rated Temperature：-65℃∽350℃
- Rated Voltage：300V/500V
- Conductor：Silver Copper
- Insulation：Special glass fiber
- Inner Protective Material:Teflon
- Shield:Steel
- Jacket:Special glass fiber
- Application:applied for temperature measuring devices, used in petrol, chemical, metallurgy, power industry etc.
|
Section (mm2) |
Conductor (mm) |
Avg.Insulation Thickness (mm) |
OD (mm) |
Max. Resistance 20℃ （≤Ω/km） |
|
0.014 |
7/0.05 |
0.15 |
0.45 |
1454 |
|
0.030 |
16/0.05 |
0.15 |
0.50 |
590 |
|
0.035 |
19/0.05 |
0.15 |
0.55 |
568 |
|
7/0.08 |
0.15 |
0.55 |
568 |
|
|
0.05 |
26/0.05 |
0.15 |
0.60 |
356 |
|
10/0.08 |
0.15 |
0.60 |
356 |
|
|
0.07 |
37/0.05 |
0.20 |
0.70 |
260 |
|
19/0.07 |
0.20 |
0.70 |
260 |
|
|
14/0.08 |
0.20 |
0.70 |
260 |
|
|
0.08 |
42/0.05 |
0.20 |
0.78 |
245 |
|
21/0.07 |
0.20 |
0.78 |
245 |
|
|
16/0.08 |
0.20 |
0.78 |
245 |
|
|
0.12 |
63/0.05 |
0.25 |
0.95 |
160 |
|
32/0.07 |
0.25 |
0.95 |
160 |
|
|
24/0.08 |
0.25 |
0.95 |
160 |
|
|
0.20 |
105/0.05 |
0.25 |
1.10 |
90.4 |
|
56/0.07 |
0.25 |
1.10 |
90.4 |
|
|
42/0.08 |
0.25 |
1.10 |
90.4 |
|
|
0.35 |
182/0.05 |
0.25 |
1.30 |
53.10 |
|
96/0.07 |
0.25 |
1.30 |
53.10 |
|
|
70/0.08 |
0.25 |
1.30 |
53.10 |
|
|
0.50 |
259/0.05 |
0.25 |
1.40 |
36.7 |
|
133/0.07 |
0.25 |
1.40 |
36.7 |
|
|
105/0.08 |
0.25 |
1.40 |
36.7 |
|
|
Remarks: able to produce according to customer’s requirement |
||||
