Technical Parameters
- Rating Temperature：-65℃∽+200℃
- Rating Voltage：450/750V
- Conductor：Tinned copper
- Insulation：Silicone Rubber
- Color:red,yellow,blue, whit,black,green,brown,gray transparen,bi- color etc.
- Shielding：Tinned copper/ stainless steel wire braid
- Application Scope：For AC RATED VOLTAGE 450/750V and below all kinds of mobile motor, steel, aviation, power plant, petrochemical and other high temperature environment use.
|
Section Area (mm2) |
Conductor （No./mm） |
Average Insulation Thickness （mm） |
Cores |
Shield Thickness （mm） |
Sheath Thickness(mm) |
Resistance At 20℃ （≤Ω/km） |
|
0.07 |
19/0.07 |
0.45 |
≤7 |
≥0.3 |
≥1.5 |
365 |
|
0.10 |
12/0.10 |
0.45 |
188 |
|||
|
0.12 |
7/0.15 |
0.45 |
160 |
|||
|
0.15 |
39/0.07 |
0.45 |
136 |
|||
|
0.2 |
12/0.15 |
0.60 |
95 |
|||
|
0.3 |
16/0.15 |
0.60 |
72 |
|||
|
0.4 |
23/0.15 |
0.50 |
50 |
|||
|
0.5 |
28/0.15 |
0.60 |
≤19 |
40 |
||
|
0.75 |
42/0.15 |
0.70 |
27 |
|||
|
1 |
32/0.20 |
0.70 |
20 |
|||
|
1.5 |
48/0.20 |
0.70 |
14 |
|||
|
2 |
40/0.25 |
0.70 |
10 |
|||
|
2.5 |
49/0.25 |
0.80 |
8.2 |
|||
|
Remarks: able to produce as customer’s requirement |
|
|||||
