Technical Parameters
- Rating Temperatures：-60°C~+ 200°C
- Rating Voltage：300V
- Testing Voltage：1500V
- Conductor：Tinned copper
- Insulation：Silicone Rubber
- Color：white,red,yellow,green,black etc.
|
Gauges AWG |
Construction mm |
Conductor Diameter mm |
Insulation Thickness mm |
Overall Diameter mm |
Resistance at 20℃ ≤Ω/km |
|
2*30 |
11/0.08 |
0.30 |
0.60 |
1.5*3.00 |
381.00 |
|
2*28 |
16/0.08 |
0.37 |
0.60 |
1.57*3.14 |
239.00 |
|
2*26 |
30/0.08 |
0.50 |
0.60 |
1.7*3.40 |
150.00 |
|
2*24 |
40/0.08 |
0.58 |
0.6o |
1.78*3.56 |
94.20 |
|
2*22 |
60/0.08 |
0.71 |
0.60 |
1.91*3.82 |
59.40 |
|
2*20 |
100/0.08 |
0.92 |
0.60 |
2.12*4.24 |
36.70 |
|
2*18 |
150/0.08 |
1.13 |
0.60 |
2.33*4.66 |
23.20 |
|
2*16 |
252/0.08 |
1.46 |
0.60 |
2.55*3.46 |
14.60 |
|
3*30 |
11/0.08 |
0.30 |
0.60 |
1.5*4.50 |
381.00 |
|
3*28 |
16/0.08 |
0.37 |
0.60 |
1.57*4.71 |
239.00 |
|
3*26 |
30/0.08 |
0.50 |
0.60 |
1.7*5.10 |
150.00 |
|
3*24 |
40/0.08 |
0.58 |
0.60 |
1.78*5.34 |
94.20 |
|
3*22 |
60/0.08 |
0.71 |
0.60 |
1.91*5.73 |
59.40 |
|
3*20 |
100/0.08 |
0.92 |
0.60 |
2.12*6.36 |
36.70 |
|
3*18 |
150/0.08 |
1.13 |
0.60 |
2.33*6.99 |
23.20 |
|
4*30 |
11/0.08 |
0.30 |
0.6o |
1.5*6.00 |
381.00 |
|
4*28 |
16/0.08 |
0.37 |
0.60 |
1.57*6.28 |
239.00 |
|
4*26 |
30/0.08 |
0.50 |
0.60 |
1.7*6.80 |
150.00 |
|
4*24 |
40/0.08 |
0.58 |
0.60 |
1.78*7.12 |
94.20 |
|
4*22 |
60/0.08 |
0.71 |
0.60 |
1.91*7.64 |
59.40 |
|
4*20 |
100/0.08 |
0.92 |
0.60 |
2.12*8.48 |
36.70 |
|
Remarks:able to produce as customer’s requirement |
|||||
