Technical Parameters
- Rating Voltage:300V
- Temperature Range:-60℃∽+200℃
- Testing Voltage:1500V
- Conductor:tinned copper, bare copper
- Insulation:Silicone Rubber
- Color:red,black,black,white,blue,brown,yellow,green
- Application：Suitable for all kinds of models, lighting, household appliances, electronic and electromagnetically internal fixed connection wire.
|
Section area (mm2) |
Construction （No./mm） |
Conductor Diameter （mm） |
Insulation Thickness （mm） |
Overall Diameter （mm） |
|
2*0.05 |
11/0.03 |
0.30 |
0.55 |
1.2*2.5 |
|
2*0.08 |
16/0.03 |
0.37 |
0.55 |
1.3*2.6 |
|
2*0.15 |
30/0.08 |
0.50 |
0.55 |
1.4*2.8 |
|
2*0.20 |
40/0.08 |
0.60 |
0.55 |
1.6*3.3 |
|
2*0.30 |
60/0.03 |
0.78 |
0.55 |
1.7*3.5 |
|
2*0.50 |
100/0.08 |
0.92 |
0.55 |
1.8*3.7 |
|
2*0.75 |
150/0.08 |
1.19 |
0.55 |
2.3*4.7 |
|
2*1.25 |
252/0.08 |
1.53 |
0.80 |
3.0*6.2 |
|
2*2.0 |
400/0.08 |
1.85 |
0.90 |
3.5*7.2 |
|
2*3.4 |
580/0.08 |
2.48 |
1.00 |
4.5*9.2 |
|
Remarks: able to produce as customer’s requirement |
||||
