Technical data:
- Rated Temperature:-65℃∽+200℃
- Rated Voltage：600V
- Conductor: Stranded Soft Silver Copper/Soft Tinned Copper
- Insulation：FEP、PFA or PTFE
- ConductorColor:Red,yellow,blue,white,black,green,brown,orange,gray,transparent,bio-color ,etc.
- Jacket:Silicone Rubber
- Jacket Color:Red,yellow,blue,white,black,green,brown,orange,gray,,etc.
- Application:High voltage wire for electrical appliances and other equipment.
|
Section (mm2) |
Conductor No. (mm) |
Avg.Insulation Thickness （mm） |
Core No. |
Jacket Thickness（mm） |
Max. Resistance 20℃ （≤Ω/km） |
|
0.014 |
7/0.05 |
0.15 |
≤37Core |
≥1.2 |
1454 |
|
0.030 |
16/0.05 |
0.15 |
590 |
||
|
0.035 |
19/0.05 |
0.15 |
568 |
||
|
7/0.08 |
0.15 |
568 |
|||
|
0.05 |
26/0.05 |
0.15 |
356 |
||
|
10/0.08 |
0.15 |
356 |
|||
|
0.07 |
37/0.05 |
0.20 |
260 |
||
|
19/0.07 |
0.20 |
260 |
|||
|
14/0.08 |
0.20 |
260 |
|||
|
0.08 |
42/0.05 |
0.20 |
245 |
||
|
21/0.07 |
0.20 |
245 |
|||
|
16/0.08 |
0.20 |
245 |
|||
|
0.12 |
63/0.05 |
0.25 |
160 |
||
|
32/0.07 |
0.25 |
160 |
|||
|
24/0.08 |
0.25 |
160 |
|||
|
0.20 |
105/0.05 |
0.25 |
90.4 |
||
|
56/0.07 |
0.25 |
90.4 |
|||
|
42/0.08 |
0.25 |
90.4 |
|||
|
0.35 |
182/0.05 |
0.25 |
≤19Core |
≥1.5 |
53. |
|
96/0.07 |
0.25 |
53.1 |
|||
|
70/0.08 |
0.25 |
53.1 |
|||
|
0.50 |
259/0.05 |
0.25 |
36.7 |
||
|
133/0.07 |
0.25 |
36.7 |
|||
|
105/0.08 |
0.25 |
36.7 |
|||
|
Remarks: able to produce according to customer’s requirement |
|||||
